2013 new style magnetic separator with low price

Price:	1.0~100000.0 USD
Payment Terms:	T/T,L/C,WU
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean

Packing: Export standard packing to ...

Application: Coal

Brand Name: zhongcheng

Motor Power(kw): 1.1

Guarantee period: one year

Color: You decide

Production Capacity: 50Set/Sets per Month

Delivery Date: 7-15 days after receiving t...

Type: Others

Handling Capacity (t/h): 8-15

Weight(t): 910

Q/C: ISO9001:2008

1.Roller size(mm):600X1800;
2.Magnetic strength:1500;
3.Handle capacity(t/h):15-25;
4.ISO.

ISO certificate iron sand Magnetic separator

1.Magnetic Separator Introduction:

Magnetic separator applies to wet magnetic separate for magnetite, pyrrhotite, roasted ore, ilmenite and other materials which grain size are less than 3mm, it also uses for deironing operation of the coal, non-metallic minerals, building materials and other materials.

2.Separator structural features:
The magnetic system of the magnetic separator composes high-quality ferrite materials and rare earth magnet, the average magnetic induction of the tube is 100 ~ 600mT. According to user demands, can provide downstream, semi-reflux, reflux-type and so many different form strong magnetic separation. The magnetic separator is of the simple structure, large coping capacity, easy operation, convenient maintenance and so on.

3.Specification and Technical Parameters:

Specification and Type	Magnetic Field Strength (oe)	Handling Capacity (t/h)	Motor Power(kw)	Machine Weight (kg)
CTB600x900	1450	8-15	1.1	910
CTB600x1800	1500	15-25	2.2	1340
CTB750x1200	1550	25-30	2.8	1490
CTB750x1800	1550	30-45	3	2050
CTB900x1800	1650	35-60	4	3000
CTB1050x2400	1650	60-95	5.5	5020
CTB1200x3000	1650	80-150	7.5	7800
CTB1500x3000	1650	120-200	11	9600

4.Service Promise:

1.Before-sale services:We guide customers to choose the best and applicable device; provide the advanced, energy-saving and practical technological process, as well as we are responsible for the planing and design of the site.

2.Sale services: Products must be inspected Strictly before being sold; customers are invited to simulate and test machine on-the-spot and raise objections; in accordance with the agreements stipulated in the contract, we will arrange delivery.

3.After-sale services:Our company will send professional engineers to guide device installation, debugg and train operators until customers are fully satisfied. Moreover, we will design and produce machines according to the special requirements of customers.

4.Solemn Promise:The quality guarantee period of machines is one year except the wearing parts.

5.Warm tips: The prices in the web only to be reference, according to raw materials price fluctuations, Specific price is subject to the call
